Tooj liab yog ib qho ntawm ntau yam thiab siv dav hlau hauv kev lag luam, khoom plig rau nws cov hluav taws xob zoo thiab thermal conductivity, corrosion kuj, thiab ua haujlwm. Ntawm ntau yam tooj liab alloys, phosphorus-deoxidized tooj liab-tshwj xeeb tshaj yogTP1 (C12000)thiabTP2 (C12200)-yog qhov tseem ceeb hauv cov ntawv thov xws li cov kav dej thiab HVAC rau hluav taws xob engineering thiab cov khoom siv hluav taws xob. Thaum lawv sib koom ntau qhov sib xws, lawv qhov sib txawv hauv kev sib xyaw, cov khoom, thiab kev siv yog qhov tseem ceeb. Kab lus no tshawb txog qhov sib txawv no los pab engineers, designers, thiab procurement specialists txiav txim siab paub.
Tshuaj muaj pes tsawg leeg
| Element | TP1 (C12000) | TP2 (C12200) |
|---|---|---|
| Cu + Ag | Ntau dua lossis sib npaug li 99.9% | Ntau dua lossis sib npaug li 99.9% |
| P | 0.004% – 0.012% | 0.015% – 0.040% |
| O | Tsawg dua lossis sib npaug li 0.01% | Tsawg dua lossis sib npaug li 0.01% |
TP1 (Low Residual Phosphorus):
Nrog cov ntsiab lus phosphorus tswj ntawm 0.004% thiab 0.012%, TP1 khaws cov hluav taws xob ntau dua thiab thermal conductivity. Qib qis phosphorus zoo deoxidizes tooj liab yam tsis muaj cuam tshuam cov electron txaus.
TP2 (Higher Residual Phosphorus):
TP2 muaj 0.015% rau 0.040% phosphorus, uas muab kev txhim kho deoxidization. Qhov no ua rau nws tshwj xeeb tshaj yog haum rau vuam thiab brazing tab sis me ntsis txo conductivity piv rau TP1.
Kev sib piv tseem ceeb
Hluav taws xob thiab Thermal conductivity
TP1 muaj hluav taws xob conductivity ntawm kwv yees li 85% IACS (International Annealed Copper Standard), ua kom nws zoo dua rau cov kev siv uas conductivity yog qhov tseem ceeb, xws li hluav taws xob busbars, connectors, thiab tshav kub exchangers.
TP2 muaj nyob ib ncig ntawm 80% IACS vim nws cov ntsiab lus phosphorus ntau dua. Txawm hais tias tseem muaj kev coj ua zoo, nws feem ntau yog xaiv rau cov ntawv thov uas conductivity yog qhov thib ob rau kev sib koom ua ke.
Weldability thiab Brazability
TP2 zoo tshaj hauv weldability thiab brazability. Cov ntsiab lus phosphorus siab dua ua tus neeg sawv cev fluxing thaum lub sij hawm brazing, txhawb nqa capillary zoo dua thiab cov pob qij txha muaj zog. Qhov no ua rau TP2 qhov kev xaiv zoo tshaj plaws rau cov kav dej, HVAC piping, thiab cov roj siv kho mob uas muaj pa tawm - cov pob qij txha dawb yog qhov tseem ceeb.
TP1 kuj muaj qhov zoo weldability tab sis tej zaum yuav xav tau kev ceev faj ntau dua thaum lub sij hawm brazing. Nws feem ntau yog siv rau hauv cov ntawv thov uas yuav tsum tau vuam tab sis tsis yog qhov tseem ceeb.
Corrosion Resistance
Ob lub alloys pom zoo heev corrosion kuj nyob rau hauv feem ntau ib puag ncig, xws li dej, atmospheric raug, thiab cov tshuaj me me. Lawv cov ntsiab lus tsis tshua muaj oxygen tiv thaiv "hydrogen embrittlement" hauv kev txo cov huab cua, ua rau lawv ruaj khov nyob rau hauv ntau yam kev pabcuam.
Mechanical Properties
Tensile Strength: TP1 thiab TP2 muaj qhov sib piv tensile lub zog (≈ 215-345 MPa, nyob ntawm qhov kub thiab txias).
Formability: Ob leeg alloys pom zoo ductility thiab txias - ua hauj lwm zog, tshwj xeeb tshaj yog nyob rau hauv lub annealed temper. TP1 cov ntsiab lus phosphorus qis me ntsis tuaj yeem muab qhov txias txias zoo dua -bending kev ua tau zoo.
Tau Dedicated Engineer Support
Common Product Forms thiab Applications
TP1 (C12000)
Cov ntawv zoo li: Tube, kav, ntawv, phaj, tuav, thiab xaim.
Cov ntawv thov tseem ceeb:
Thaum tshav kub kub exchangers thiab condensers
Cov khoom siv hluav taws xob (busbars, connectors)
Industrial fluid transfer systems
General engineering thiab fabrication
TP2 (C12200)
Hom Hom: Feem ntau yog cov raj thiab cov kav dej.
Cov ntawv thov tseem ceeb:
Cov kav dej thiab cov kav dej siv tau
HVAC thiab tub yees tub yees
Kev kho mob roj kab
Brazed los yog welded sib dhos yuav tsum muaj kev sib koom ua ke siab
Yuav Ua Li Cas Xaiv Ntawm TP1 thiab TP2
Xaiv TP1 yog tias:
Hluav taws xob lossis thermal conductivity yog qhov tseem ceeb.
Daim ntawv thov suav nrog cov khoom siv hluav taws xob, hloov hluav taws xob, lossis kev tsim khoom dav dav uas qhov kev sib koom ua ke tsis yog ib qho kev tsom.
Koj xav tau kev sib npaug ntawm kev coj ua, lub zog, thiab kev ua haujlwm.
Xaiv TP2 yog tias:
Kev yooj yim ntawm brazing lossis vuam yog qhov tseem ceeb (piv txwv li, kav dej, HVAC, kev kho mob roj).
Kev ntseeg tau sib koom ua ke thiab kev tiv thaiv cov dej xau yog qhov tseem ceeb tshaj plaws.
Me ntsis qis conductivity yog siv tau rau daim ntawv thov.
Peb cov khoom lag luam
| Yam khoom | Cov ntawv tseem ceeb ntawm cov khoom | Common Standards (Piv txwv) | Hom Kev Siv / Nta |
|---|---|---|---|
| Copper Rods & Bars | Round Rods, Square Bars, Hexagonal Bars | ASTM B187, C11000, C10200; EN 12163-66; JIS H3250 | Hluav taws xob conductors, machined qhov chaw, connectors, kho vajtse. Muaj nyob rau hauv ntau tempers (mos, nyuaj). |
| Copper Tubes & Cov kav dej | Seamless Tubes, Ncaj Ntev, Coils (rau cov raj hloov tau) | ASTM B75, B280, B88; EN 12735; JIS H3300 | Cov kav dej, HVAC / R, cov khoom siv hluav taws xob sib hloov, cov kab hluav taws xob kho mob, cov tshuab hydraulic. |
| Copper Phaj & Ntawv | Plates (>6mm thickness), Cov ntawv (<6mm thickness) | ASTM B152, C11000; EN 1652; JIS H3100 | Architectural cladding, industrial fabrication, grounding daim hlau, chemical processing. |
| Copper Strips & Foils | Strips, Rolls, Precision Foils | ASTM B272, C11000; EN 1652; JIS H3100 | Hluav taws xob tiv tauj, transformers, shielding, gaskets, hniav inlays. |
| Tooj Hlau | Tooj liab hlau, Stranded hlau, Busbars | ASTM B1, B3, B187; EN 13601; JIS H3260 | Windings, cables, busbars, fasteners, vuam electrodes. |
Peb lub Hoobkas
Peb muab tag nrho cov khoom siv tooj liab- qws, raj, phaj, tuav, xov hlau, thiab strips-tsim raws li thoob ntiaj teb specifications xws li ASTM, BS, thiab JIS. Peb lub peev xwm tsim khoom muaj cov kab rov tav nruam nruam rau cov loj- kab kab kab, cov kab tho rotary rau siab- cov raj muaj tseeb, thiab ntau- yob tiav mills rau ultra- nyias strips. Txhawm rau kom ntseeg tau tias qhov zoo tshaj plaws, peb siv cov txheej txheem kev soj ntsuam dav dav: tshuaj ntsuam xyuas ntawm XRF, kev txheeb xyuas cov cuab yeej cuab tam ntawm cov tshuab ntsuas thoob ntiaj teb, thiab tsis yog- kuaj kev puas tsuaj (ultrasonic thiab eddy tam sim no) rau kev ncaj ncees sab hauv thiab saum npoo. Nrog rau kev tsim khoom, kev tshuaj xyuas nruj, thiab kev hloov kho yooj yim, peb xa cov khoom siv tooj liab siab tshaj plaws rau hluav taws xob, HVAC, tshuab, thiab kev tsim kho kev lag luam thoob ntiaj teb.
