H96 tooj dag yog dab tsi?
C2100/H96 tooj dag coils thiab strips yog ib qho pheej yig alloy nrog nruab nrab conductivity thiab siab dua - nruab nrab lub zog. GNEE muaj kev paub dhau los hauv kev tsim khoom thiab muab cov khoom zoo ntawm - tooj dag coils thiab strips.C2100 Brass Coil & Strip yog hu ua gilding hlau, C210 yog ib qho kev lag luam alloy nrog kev coj ua nruab nrab thiab siab dua - lub zog nruab nrab.
C2100 Brass Coil & Sawb Specifications
Tshuaj muaj pes tsawg leeg
|
Cu |
Pb |
Zn |
Fe |
Tag nrho impurity |
|
95.0~97.0 |
Tsawg dua lossis sib npaug li 0.03 |
REM |
Tsawg dua los yog sib npaug li 0.1 |
Tsawg dua los yog sib npaug li 0.2 |
Lub cev muaj zog
|
Qib |
Tensile zog (N / hli) |
Elongation (%) |
Hardness (HV) |
||||||||
|
Mos |
1/2H |
H |
Mos |
1/2H |
H |
Mos |
1/4H |
1/2H |
3/4H |
H |
|
|
C2100 |
Ntau dua lossis sib npaug li 205 |
270-345 |
Ntau dua lossis sib npaug li 280 |
Ntau dua lossis sib npaug 33 |
Ntau dua lossis sib npaug li 18 |
- |
Tsawg dua los yog sib npaug li 65 |
65~80 |
80-100 |
- |
Ntau tshaj los yog sib npaug rau 100 |
|
Thickness |
0.3 hli ~ 30mm |
|
Dav |
50mm ~ 2000mm |
C2100 Brass Coil & Sawb Daim Ntawv Thov
Auto Parts
Drilling
Engineering Machinery
Tshuab dhos
Shipbuilding
Kev sib kis
FAQ
| Q: H96 tooj dag tuaj yeem welded lossis soldered? A: Yog, nws muaj qhov zoo heev solderability thiab brazability. Txawm li cas los xij, vuam tuaj yeem nyuaj vim nws cov thermal conductivity thiab zinc cov ntsiab lus, uas tuaj yeem ua rau porosity thiab zinc fume. Cov txheej txheem tshwj xeeb (xws li TIG vuam nrog cov hlau ua kom zoo) yuav tsum tau ua. |
| Q: Cov qauv tseem ceeb uas npog H96 / C21000 yog dab tsi? A: Nws tau them los ntawm ntau yam qauv thoob ntiaj teb: Tuam Tshoj: GB / T 5231 (H96) USA: ASTM B36 (C21000 rau daim ntawv / phaj / sawb), ASTM B134 (C21000 rau hlau) Teb chaws Europe: EN CW500L (zoo sib xws) Nyiv: JIS C2100 |
| Q: Puas yog H96 tooj dag resistant rau dezincification? A: Yog, nws muaj kev tiv thaiv siab heev rau dezincification vim nws cov ntsiab lus tooj liab siab (siab dua 85%). Qhov no ua rau nws tsim nyog siv rau hauv qee qhov chaw aqueous uas qis dua - tooj liab tooj liab (xws li H70, H62) yuav raug cuam tshuam. |
| Q: Dab tsi yog daim ntawv thiab qhov loj me rau cov khoom H96? A: Nws yog feem ntau muab los ua sawb / coil, ntawv / phaj, xaim, thiab raj. Tej qhov ntev muaj xws li: Sawb/Coil: Thickness 0.1mm - 3.0mm, Dav mus txog 600mm. Hlau: Txoj kab uas hla 0.5mm - 12.0mm. Tube: Outer Diameter (OD) 3mm - 50mm. |
| Q: Dab tsi yog temper (lub xeev hardness) muaj rau H96 sawb? A: Nws yog feem ntau muaj nyob rau hauv mos (O), quarter- nyuaj (H01), ib nrab- nyuaj (H02), thiab nyuaj (H04) tempers kom haum raws li cov kev cai sib txawv. |
| Q: Tus nqi ntawm H96 piv rau lwm yam tooj dag thiab tooj liab li cas? A: Vim nws cov ntsiab lus tooj liab siab, nws tus nqi siab dua li cov tooj dag xws li H62 thiab H68, tab sis feem ntau qis dua cov tooj liab ntshiab thiab hwm alloys xws li phosphor bronze. Nws muaj qhov sib npaug zoo ntawm kev ua haujlwm thiab tus nqi. |
| Q: Dab tsi yog qhov tseem ceeb ntawm cov khoom tiav rau H96 / C21000 tooj dag? A: Cov txheej txheem tiav rau H96 / C21000 tooj dag suav nrog zeb tiav (matte), polished, thiab ntau yam coated tiav (xws li cov lacquer ntshiab lossis passivation) los tiv thaiv tarnishing, tshwj xeeb tshaj yog rau kev siv kho kom zoo nkauj. |
| Q: Puas yog H96 haum rau kev ua cov springs? A: Yog, nws zoo ua ke ntawm conductivity, corrosion kuj, thiab caij nplooj ntoos hlav zog (nyob rau hauv hardened tempers) ua H96 / C21000 ib tug nyiam cov khoom rau tej yam hluav taws xob conductivity springs thiab hu. |
| Q: H96 ua haujlwm li cas ntawm kev ua haujlwm? A: Nws qhov kev ntsuas kev ua tau zoo kuj qis (ze li 20% ntawm qhov dawb - txiav tooj dag C36000=100% nplai). Nws yog gummy thiab nyiam ua raws li cov cuab yeej txiav. Nws tsis yog feem ntau xaiv rau siab - ntim tshuab ua haujlwm. |
| Q: Puas yog H96 los ntawm Tuam Tshoj thiab C21000 los ntawm Tebchaws Meskas raws nraim tib yam? A: Lawv yog cov qib sib npaug nrog ze li qhov sib npaug nominal compositions. Qhov sib txawv me me tuaj yeem muaj nyob rau hauv qhov tso cai impurity theem ntawm GB (Suav) thiab ASTM (US) cov qauv. Rau feem ntau cov ntawv thov, lawv suav hais tias hloov pauv tau, tab sis cov ntawv thov tseem ceeb yuav tsum txheeb xyuas cov kev cai tshwj xeeb. |
| Q: Puas H96 / C21000 tooj dag siv tau rau kev siv dej hiav txwv? A: Nrog nws cov corrosion kuj thiab dezincification tsis kam, H96 / C21000 tooj dag tuaj yeem siv rau hauv qee qhov qis -corrosion marine ib puag ncig (xws li, cov khoom siv sab hauv, cov khoom siv kho kom zoo nkauj). Txawm li cas los xij, rau cov ntawv thov dej hiav txwv tseem ceeb, cov khoom tshwj xeeb ntxiv xws li txhuas tooj dag lossis tooj liab -nickel raug pom zoo tshaj H96 tooj dag. |
Peb cov khoom lag luam
| Qeb | Lwm Cov Qib Tseem Ceeb (Extensive Range) | Cov Khoom Muag Khoom | Hom Loj Loj |
|---|---|---|---|
| Ntshiab tooj liab | T2 (C11000/C10100), TU1/TU2 (Oxygen{5}}Free), T3 (C11000), C10100, C10200 (OF), C10300, C10400, C10500, C10700, C1011300, C, C1 C11500, C11600, C12000, C12200 | Tube / Tube, Phaj / Sheet, Coil / Sawb, Hlau / Qws, Busbar | Tube / Tube: OD 3mm - 400mm, WT 0.5mm - 15mm Sheet/Plate/Coil: Thk 0.1mm - 50mm, Dav Tsawg dua los yog sib npaug li 1250mm Hlau / Qws: Dia. 0.5mm - 80mm |
| Phosphorus Deoxidized Copper | TP2 (C12200), C1201, C1220, C12200, C14200 | Tube / Tube, Phaj / Sheet, Coil / Sawb | Tube / Tube: OD 4mm - 300mm, WT 0.5mm - 10mm Sheet/Plate/Coil: Thk 0.2mm - 30mm, Dav Tsawg dua los yog sib npaug li 1000mm |
| tooj dag | H96, H68, H65, H70, HPb59-1 (C3771), CW505L (C12200), C2600 (Cartridge Brass), C2680, C2720, C28000, C36000 (Free-Txiav), C38500 | Coil / Sawb, Phaj / Sheet, Qws / Bar, Hlau | Sawb / Sheet / Coil: Thk 0.05mm - 10.0mm, Dav Tsawg dua lossis sib npaug li 650mm Qws/Bar: Dia. 3mm - 200mm Hlau: Dia. 0.5mm - 12mm |
| Bronze & Lwm yam Alloys | Phosphor Bronze: C51000, C52100, C54400 Copper -Nickel: C71500, C71640 Aluminium Bronze: C60600, C63000 Beryllium tooj liab: C17200, C17500 Lwm yam: C19210, C19400 |
Sawb / Coil, Phaj, Qws / Bar, Hlau, Yeeb | Customizable rau alloy thiab daim ntawv. Sawb/Coil: Thk 0.05mm - 5.0mm Qws / Bar: Dia. mus txog 150 mm |
