TP1/C12000 Cua Txias Copper Pipe
C12000/TP1 Copper Pipe yog dab tsi?
C12000 tooj liab yeeb nkab muaj hluav taws xob zoo heev thiab thermal conductivity nrog nws siab purity tooj liab matrix. Tsis tas li ntawd, nws muaj kev ua haujlwm zoo thiab ua haujlwm zoo nrog ntau yam kev ua haujlwm txias thiab kub, xws li forging, dov, kos duab thiab stamping. Qhov no ua rau C12000 tooj liab kav siv dav hauv kev tsim cov xov hlau, cables, cov khoom siv hluav taws xob, cov khoom siv tsheb, HVAC thiab cov khoom siv tub yees thiab lwm yam. Ntxiv nrog rau nws cov khoom zoo ntawm lub cev, C12000 tooj liab yeeb nkab kuj muaj qhov zoo tshaj plaws corrosion kuj, tshwj xeeb tshaj yog nyob rau hauv ib puag ncig ntub thiab av. Qhov no tso cai rau nws tswj kev ua haujlwm ruaj khov nyob rau hauv cov xwm txheej uas yuav tsum tau muaj kev cuam tshuam ntev rau qhov chaw hnyav.
Tau txais TP1 Copper Tube Spec Sheet
C12000 / TP1 Hom K / L / M Copper TubeTshuaj muaj pes tsawg leeg
|
Tooj + Nyiaj Nrog Ag: |
Tin Sn: |
Zinc Zn: |
Coj Pb: |
Nickel Nws yog: |
Hlau Fe: |
|
Ntau dua lossis sib npaug rau 99.90 |
Tsawg dua lossis sib npaug li 0.002 |
Tsawg dua los yog sib npaug li 0.005 |
Tsawg dua los yog sib npaug li 0.005 |
Tsawg dua los yog sib npaug li 0.005 |
Tsawg dua lossis sib npaug li 0.01 |
|
Antimony Sb: |
Sulfur S: |
Arsenic Raws li: |
Bismuth Bi: |
Oxygen O: |
Phosphorus P: |
|
Tsawg dua lossis sib npaug li 0.002 |
Tsawg dua los yog sib npaug li 0.005 |
Tsawg dua lossis sib npaug li 0.002 |
Tsawg dua lossis sib npaug li 0.002 |
Tsawg dua lossis sib npaug li 0.01 |
0.005-0.012 |
C12000 / TP1 cua sov thiab txias tooj liab kavMechanical Properties
|
Tensile zog Kb (MPa): |
Elongation D10 (%): |
Hardness: |
|
245-345 |
Ntau dua lossis sib npaug li 8 |
75-120 HV |
C12000/TP1 AC Copper Pancake Tubing Lub cev muaj zog
|
Khoom |
Tus nqi |
|
Qhov ceev (g / cm³) |
8.94 |
|
Melting Point (zeeg) |
1083 |
|
Hluav taws xob conductivity (%IACS) |
98 – 100 |
|
Thermal conductivity (W / m · K) |
391 (ntawm 20 degree) |
Ntawm no yog lub rooj ntawm qhov loj me peb tuaj yeem muab rau C12000 tooj liab raj
| Parameter | Ntau yam / Specification | Sau ntawv |
|---|---|---|
| Sab nraud Diameter (OD) | 3mm ~ 300 hli | tuaj yeem kho tau hauv qhov ntau. |
| Phab ntsa Thickness | 0.3 hli ~ 12 hli | Ua raws li qhov sib txawv OD qhov ntau thiab tsawg thiab cov qauv siv. |
| Txheem Length | Txoj kab ncaj nraim: 1 m ~ 6 m Coils: Mus txog 50 m |
Ncaj ntev yog tus qauv; coils muaj rau me me diameters. |
| Temper Xeev | Mos (Annealed) / Ib nrab - nyuaj / Hard | Feem ntau rau cov khoom siv hluav taws xob sib txawv: mos (O61) lossis ib nrab- nyuaj (H55). |
| Txuj | ASTM B280, ASTM B88, EN 12735, GB / T 17791, thiab lwm yam. | Nyob ntawm daim ntawv thov (tub yees, kav dej, thiab lwm yam). |
| Hom OD Qhov ntau thiab tsawg (Cov tub yees) | 6.35mm (1/4 "), 9.52mm (3/8"), 12.7mm (1/2"), 15.88mm (5/8"), 19.05mm (3/4") | Imperial qhov ntau thiab tsawg tau siv dav hauv HVAC & R. |
| Ua siab ntev | Raws li ASTM B280 lossis cov neeg siv khoom tshwj xeeb | Standard tolerances ntawm OD, phab ntsa thickness, thiab roundness. |
Nug txog TP1 Tube Nqe & Cov Qauv
Yog vim li cas C12000 / TP1 Copper Pipe yog haum rau cua txias
Qhov zoo tshaj plaws tshav kub hloov-Qhov siab tshaj thermal conductivity ntawm cov hlau siv tau rau kev ua kom txias.
Yooj Yim Ua Haujlwm Nrog- Mos temper cia yooj yim khoov; solders/brazes zoo kawg nkaus rau leak{0}}cov ntaub ntawv pov thawj.
Corrosion Resistant- Ib txwm tiv taus ya raws, huab cua, thiab cov tub yees rau ntau xyoo.
Strong & Durable- Tuav lub zog siab thiab tiv thaiv kev tawg hauv qab vibration / cycling.
Huv & nyab xeeb- Antimicrobial nto inhibits pwm / kab mob loj hlob hauv tubing.
Qhov sib txawv ntawm C12000 / TP1 thiab TP2 / C12200.
| Feature | C12000 / TP1 (Low{2}}Cov Phosphorus seem) | TP2 / C12200 (Standard Phosphorus) |
|---|---|---|
| 1. Phosphorus (P) Cov ntsiab lus | Tsawg: 0.004% - 0.012% | Siab dua: 0.015% - 0.040% |
| 2. Thawj Qhov Zoo | Higher Thermal & Hluav Taws Xob Conductivity (ze dua rau cov tooj liab ntshiab). | Superior Brazing / Soldering yam ntxwv thiab zoo heev corrosion kuj. |
| 3. Daim ntawv thov zoo tshaj plaws | High -Kev ua tau zoo Thaum tshav kub kub Exchangers qhov siab tshaj plaws hloov hluav taws xob yog qhov tseem ceeb. | Plumbing & General Tubing Tubing qhov twg txhim khu kev qha kev koom ua ke thiab tag nrho durability yog qhov tseem ceeb. |
| 4. Kev lag luam tseem ceeb -tawm | Tus nqi qis dua; marginally tsawg oxide-dawb nto rau brazing vs. TP2. | Tsawg conductivity vim ntau dua phosphorus impurity. |
Siv C12000/TP1 thaum koj qhov tseem ceeb yog qhov ua tau zoo tshaj plaws thermal (xws li, siab-kawg condenser/evaporator coils).
Siv TP2 / C12200 rau feem ntau cov ntawv thov (dej kav dej, cov qauv AC) qhov twg nws zoo heev brazeability thiab pov thawj kev ntseeg tau zoo tagnrho.
FAQ
Q1: Dab tsi yog qhov txiaj ntsig tseem ceeb ntawm kev siv C12000 / TP1 tshaj lwm hom tooj liab hauv cov cua txias?
A:Nws lub ntsiab kom zoo dua yog superior thermal conductivity. Vim nws cov ntsiab lus phosphorus qis dua, C12000 / TP1 ua kom muaj cua sov zoo dua li TP2 / C12200 ntau dua, ua rau muaj peev xwm ua tau zoo dua qub thiab hloov hluav taws xob sai hauv condensers thiab evaporators.
Q2: Puas yog C12000 / TP1 haum rau txhua qhov chaw ntawm AC refrigerant circuit?
A:Yog, nws yog qhov zoo heev rau tag nrho cov kab hluav taws xob, suav nrog cov kab txuas, evaporator coils, thiab condenser coils. Nws ua ke ntawm lub zog, formability, thiab corrosion kuj ua rau nws muaj kev daws teeb meem.
Q3: Puas yog nws nyuaj rau braze lossis solder dua cov qauv tooj liab zoo li TP2?
A:Tsis yog, feem ntau nws yooj yim heev rau braze. Cov phosphorus ua haujlwm zoo li deoxidizer, tiv thaiv oxide tsim thaum cua sov. Thaum TP2 feem ntau raug suav hais tias muaj cov yam ntxwv "zoo tshaj" brazing, C12000/TP1 muab kev ua tau zoo, txhim khu kev qha, thiab xau{5}} cov qauv sib koom ua ke pub dawb hauv kev lag luam.
Q4: Vim li cas ho tsis yog C12000 / TP1 cov tooj liab feem ntau yog tias nws muaj kev ua tau zoo dua?
A: Tus nqi vs. Kev xav tau ntawm kev ua haujlwm.TP2 / C12200 muaj qhov zoo tshaj plaws brazeability, corrosion kuj, thiab zoo txaus conductivity rau feem coob ntawm cov qauv siv ntawm tus nqi sib tw. C12000/TP1 feem ntau tau teev tseg rau siab -kev ua tau zoo lossis kev hwm zoo uas qhov kev ua tau zoo tshaj plaws ua kom pom tseeb tus nqi khoom siab dua me ntsis.
Q5: Nws cov kav ntev npaum li cas piv rau TP2 hauv AC systems?
A:Durability yog sib npaug zoo heev. Ob lub alloys muaj kev tiv thaiv zoo tshaj plaws tiv thaiv cov dej noo, tub yees, thiab atmospheric tej yam kev mob. Lub zog ntawm tooj liab ua kom ntseeg tau tias ob qho tib si tuaj yeem tiv taus lub zog thiab thermal cycling rau lub neej ua haujlwm ntev ntawm AC chav tsev.
Peb lub Hoobkas
Peb lub Hoobkas tshwj xeeb hauv kev tshawb fawb thiab kev tsim kho, kev tsim khoom, thiab kev tswj xyuas zoo ntawm - cov raj tooj liab zoo. Nruab nrog niaj hnub precision dov thiab kos cov kab ntau lawm, peb nruj me ntsis ua raws li ntau yam kev cai thoob ntiaj teb, suav nrogASTM B280 (Seamless Copper Tube rau Cua Txias thiab Tub Txias Field), ASTM B88 (Seamless Copper Water Tube), thiab ASTM B75 (Seamless Copper Tube). Peb cov kws tshaj lij tsim seamless tooj liab raj tsim rau cua txias thiab tub yees, lub tsev dej, thiab kev siv hluav taws xob sib pauv. Los ntawm cov txheej txheem nruj xws li kev ntsuas tam sim no thiab kev tshuaj xyuas spectral, peb xyuas kom meej tias txhua lub raj tooj liab xa cov thermal conductivity zoo heev, sealing kev ua tau zoo, thiab corrosion kuj. Peb muab cov neeg siv khoom thoob ntiaj teb nrog kev ntseeg siab, cov khoom lag luam raws li thoob ntiaj teb thiab cov kev daws teeb meem.
Copper khoom ntim
Rau tooj liab coiled raj, peb txais yuav ib tug customized coil ntim tshuaj: txhua kauj yog mob nyob ib ncig ntawm ib tug siab - muaj zog muaj ntawv core los yog yas winding core rau kev them nyiaj yug, tag nrho qhwv nrog vapor corrosion inhibitor (VCI) zaj duab xis thiab kaw thaum kawg. Tom qab ntawd nws muab tso rau hauv lub siab- tiv taus corrugated cardboard lub tog raj kheej lossis lub thawv kev cai, thiab thaum kawg tau ruaj ntseg ntawm IPPC- qauv ntoo pallet. Nrog ntug tiv thaiv thiab steel strapping reinforcement, peb xyuas kom meej lub kauj tswj nws cov duab, tseem muaj kev tiv thaiv ntawm ya raws thiab cuam tshuam, thiab ua tau raws li thoob ntiaj teb kev xa khoom.
Tau Txais Cov Lus Qhia Ceev & Logistics Plan
