C90500 Tin Bronze
C90500 Tin Bronze "SAE 62"
ASTM B505, ASTM B584, ASTM B271, SAE 62
Kev Siv C90500 Tin Bronze "SAE 62":
BUILDERS HARDWARE:Clamps
Lub tsev:Khoom siv hnyav hnyav
Hluav taws xob:Cov khoom sib txuas
FASTENERS:Txiv ntseej
INDUSTRIAL:Lub cev twj tso kua mis, Valves, Iav, Piston Rings, Pump Impellers, Bushings, Bearings, Worm Gears, Expansion Bearings, Gear Blanks, Finishing Dies for Wood Pulp Industry, Valve Bodies, Seal Rings
TSEEM CEEB:Cov Cua Txias Dej, Chav Fittings
Taw qhia
Bronze - tooj liab casting alloy UNS C90500 yog cam khwb cia hlau ntawm tooj liab-tin. Bronze yog nyiam los ntawm architects rau nws cov luster ntxim nyiam thiab lub neej ntev.
- Tshuaj muaj pes tsawg leeg
- Kub
- Mechanical Properties
- Lub cev muaj zog
- Fabrication
- Specifications
| Al | Sb | Cu | Fe | Pb | Ni | P | Si | S | Sn | Zn | |
| Min/Max | 0.005 | 0.2 | 86.0 - 89.0 | 0.2 | 0.2 | 1 | 0.05 | 0.005 | 0.05 | 9.0 - 11.0 | 1.0 - 3.0 |
| Nominals | - | - | 87.5000 | - | - | - | - | - | - | 10.0000 | 2.0000 |
Lub cev muaj zog
Cov lus hauv qab no qhia txog cov khoom siv lub cev ntawm UNS C90500 alloy.
| Cov khoom | Metric | Imperial |
|---|---|---|
| Qhov ntom | 8.72 g / cm²3 | 0.315 lb/in³ |
Mechanical Properties
Cov khoom siv kho tshuab ntawm UNS C90500 alloy yog qhia hauv cov lus hauv qab no.
| Cov khoom | Metric | Imperial |
|---|---|---|
| Hardness, Brinell | 75 | 75 |
| Lub zog tensile | 310 MPa | 45 000 psi |
| Yield zog | 150 MPa | 21 800 psi |
| Elongation thaum so | 25.00% | 25.00% |
| Machineability | 30 | 30 |
| Compressive zog | 275 MPa rau | 3 9900 psi |
| qaug zog | 9 0.0 MPa | 13 100 psi |
| Izod cuam tshuam | 14.0 J | 10.3 ft ib |
| Elastic modulus | 117 GPa | 1 6969 tzs |
| Poisson tus ratio | 0.34 | 0.34 |
Thermal khoom
Cov lus hauv qab no tham txog cov khoom thermal ntawm UNS C90500 alloy.
| Cov khoom | Metric | Imperial |
|---|---|---|
| Thermal expansion co-efficient (@20-300 degree /68-572 degree F) | 2 0.0 µm/m degree | 11. 0 µin/in degree F |
| Thermal conductivity(@20.0 degree /68 degree F) | 74. 0 W/mK | 514 BTUin/hr.ft². degree F |
Lwm Lub Npe
Cov npe sib npaug rau UNS C90500 alloy suav nrog:
TIAB SA 4845
ASTM B22
ASTM B 271 Cov Lus Qhia
ASTM B30
ASTM B 505 Cov khoom siv
ASTM B584
ASTM B763 Cov khoom lag luam
qw c390
SAE J461
SAE J462
Fabrication thiab kho cua sov
Machineability
UNS C90500 alloy muaj qhov ntsuas kev ua haujlwm ntawm 30.
Vuam
Cov txheej txheem vuam nyiam rau UNS C90500 alloy yog soldering, brazing, carbon arc vuam, oxyacetylene vuam, roj shielded arc vuam thiab coated hlau arc vuam.
